Product: 3M™ Double Coated Tape 9495LE
3M™ Double Coated Tape 9495LE
Highlights
- Adds dimensional stability to foams and other substrates and also makes it easier to handle the tape during slitting and die-cutting
- 3M™ Double Coated Tape 9474LE features a dual liner for ease in selective die cutting
- The bond strength of 3M™ Laminating Adhesive 300LSE increases as a function of time and temperature, and has very high initial adhesion
- High bonding strength to LSE plastics
- Film carrier adding dimensional stability to foams and other substrates
- Film carrier makes for easy handling during slitting and die-cutting
3M™ Double Coated Tape 9495LE provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The acrylic adhesive also provides excellent adhesion to surfaces contaminated lightly with oil typically used with machine parts.
3M™ Double Coated Tape 9495LE is a 6.7 mil thick, clear tape that provides high bond strength to most surfaces, including many low surface energy (LSE) plastics such as polypropylene and powder coated paints. Use on low surface energy surfaces and as plastic extrusion attachment. It also improves handling and ease of die-cutting.
Recommended Applications
- Foam to powder coated painted surfaces
- Low surface energy plastic adhesion
- Lens bonding applications
- Logo bonding
- Touchpad bracket assembly
- Battery bonding
- Low surface energy bonding
- Memory card bonding
- Case assembly
- Camera module assembly
- Bezel bonding
- Display bonding
- Cover lens bonding
- Electronic component bonding
- Module bonding to PET card
- Battery door attachment
- Speaker module assembly
- Electrical insulation bonding
- Touchpad assembly
- Touch panel bonding
- Rubber feet bonding
Coats on Both
In general, double coated tape is composed of a paper, film or tissue carrier that is coated on both sides with pressure sensitive adhesive. The adhesive is protected by a peel-away liner that can be removed at the time of application or left in place until the joining surfaces are ready to be attached. These tapes can be applied by hand or with a dispenser. Double coated tape dispensers are available in a variety of configurations ranging from manual to fully automatic. Applications for double coated tape are found in construction, fabrication, arts and hobbies.
Bringing Better Ideas to the Surface through Science and Innovation
In our 3M Industrial Adhesives and Tapes Division, we apply the science of adhesion to deliver innovative solutions that improve the design and manufacturing processes of companies around the world. In the end, our technologies help customers like you deliver competitive products to the market faster and more efficiently.
| Adhesive Type | Acrylic, Low Surface Energy Acrylic Adhesive 300LSE |
|---|---|
| Application | Touchpad Bracket Assembly, Touch Panel Bonding, Rubber Feet Bonding, Speaker Module Assembly, Memory Card Bonding, Logo Bonding, Module Bonding to PET Card, Low Surface Energy Bonding, Electrical Insulation Bonding, Cover Lens Bonding, Case Assembly, Bezel Bonding, Touchpad Assembly, Electronic Component Bonding, Display Bonding, Camera Module Assembly, Battery Door Attachment, Battery Bonding |
| Back Side Adhesive Thickness (Imperial) | 3.4 mil |
| Back Side Adhesive Thickness (Metric) | 0.086 mm |
| Back Side Adhesive Type | Low Surface Energy Acrylic Adhesive 300LSE |
| Backing (Carrier) Material | PET, Polyester Film |
| Backing (Carrier) Thickness (Imperial) | 0.5 mil |
| Backing (Carrier) Thickness (Metric) | 0.013 mm |
| Brands | 3M™ |
| Face Side Adhesive Thickness (Imperial) | 2.8 mil |
| Face Side Adhesive Thickness (Metric) | 0.071 mm |
| Face Side Adhesive Type | Low Surface Energy Acrylic Adhesive 300LSE |
| Industries | Electronics, General Industrial, Construction |
| Maximum Operating Temperature (Fahrenheit) | 300 ℉ |
| Minimum Operating Temperature (Fahrenheit) | -40 ℉ |
| Overall Length (Imperial) | 60 yd, 180 yd, 50 yd, 10 yd |
| Overall Length (Metric) | 54.86 m, 164.59 m, 54.864 m |
| Overall Width (Imperial) | 1 in, 27 in, 8 in, 54 in, 4 in, 3.6 in, 4.5 in, 60 in, 0.75 in |
| Overall Width (Metric) | 25.4 mm, 685.8 mm, 203.2 mm, 1,371.6 mm, 101.6 mm, 91.44 mm, 114.3 mm, 1,524 mm, 19.05 mm |
| Primary Liner | 58# Polycoated Kraft Paper |
| Product Color | Transparent |
| Total Tape Thickness without Liner (Imperial) | 0.007 in, 6.7 mil |
| Total Tape Thickness without Liner (Metric) | 0.17 mm |
